ISLA FARO X
Cod. 02119101
EAN 8422248074230
Product specifications
GENERAL INFORMATION
EAN/UPC
8422248074230
Subfamily
Island
Product sheet according to directives EU65/2014 - EN61591, EN60704-2-13, EN50564
AEC (Annual energy consumption) (kWh/year)
56,3
EEI class (energy efficiency class)
A
FDE (fluid dynamic efficiency)
30,6
FDE class (fluid dynamic efficiency class)
A
LE (light efficiency) (lux/W)
36
LE class (light efficiency class)
A
GFE (grease filtering efficiency)
91,2
GFE class (grease filtering efficiency class)
B
Airflow in normal mode MIN (m3/h)
340
Airflow in normal mode MAX (m3/h)
600
Airflow in boost mode MIN (m3/h)
800
Acoustic power in normal mode MIN (dB)
50
Acoustic power in normal mode MAX (dB)
65
Acoustic power boost mode (dB)
67
Po (energy consumption in off mode) (W)
0,26
Ps (energy consumption in standby mode) (W)
0
Integration directive EU 66/2014
ƒ (time increase factor)
0,9
EEI (Energy Efficiency Index)
53,7
QBEP (maximum efficiency at air flow point) (m3/h)
416,9
PBEP (maximum efficiency at pressure point) (Pa)
411
WBEP (power consumption at maximum efficiency) (W)
155,7
WL (nominal power lighting system) (W)
7
EMIDDLE (Average illuminance on the cooking surface) (lux)
252
External Dimensions
Width (mm)
40
Depth (mm)
400
Maximum total height (mm)
1090
Minimum total height (mm)
700
Diamètre de sortie (mm)
150, 125
Characteristics
Motor quantity
1
Motor model
BT3
Maximum pressure (Pa)
450
Filter technology
Aluminium mesh
Control technology
PANEL ELECTRONICO
Booster
√
Power levels
3
Timer
√
Filter saturation indicator
-
Charcoal filter replacement indicator
-
Dimmer function
-
Connectivity
-
Remote control
-
Display
-
Lighting
Light model
ECOLED
Ray technology
LED
Installation
Minimum distance to electric plate (mm)
650
Minimum distance to gas plate (mm)
650
Recirculation option
√
Charcoal filter
-
Back draught shutter
-
Inner shield
√
Electric connection
Nominal voltage (V)
220-240
Nominal frequency (Hz)
50
Nominal input power (W)
287
Electric shock protection
Class II
Plug type
Type C
Accessories
Upper decorative duct extension
No
White decorative duct
No
Black decorative duct
No
Island tube booster
No
Back draught shutter
2832004
MAX PRO Metal filter
No
Activated charcoal filter
No
Noiseless flexible duct
2893002
Recirculation kit
No
