CORONA X 100
Cod. 02180308
EAN 8422248198547
INFORMACIÓN GENERAL
EAN/UPC
8422248198547
Subfamily
Integrated
Product fiche according to directives EU65/2014 - EN61591, EN60704-2-13, EN50564
AEC (Energy consumption per year) (kWh/año)
53,9
EEI class (Energy efficiency class)
A
FDE (Fluid dynamic efficiency)
30,6
FDE class (Fluid dynamic efficiency class)
A
LE (Light efficiency) (lux/W)
55,7
LE class (Light efficiency class)
A
GFE (Grease filtering efficiency)
84,27
GFE Class (Grease filtering efficiency class)
C
Normal mode airflow MIN (m3/h)
340
Normal mode airflow MAX (m3/h)
600
Boost mode airflow (m3/h)
850
Normal mode acustic power MIN (dB)
50
Normal mode acustic power MAX (dB)
65
Boost mode acustic power (dB)
67
Po (Off-mode power consumption) (W)
0,45
Ps (Stand-by power consumption) (W)
0
Integration directive EU 66/2014
ƒ (Factor Increase in the time)
0,9
QBEP (Maximum airflow point efficiency) (m3/h)
416,9
PBEP (Maximum pressure point efficiency) (Pa)
411
WBEP (Electrical power consumption at maximum efficiency) (W)
155,7
WL (Rated power lighting system) (W)
3,5
EMIDDLE (Average illuminance on the cooking surface) (lux)
195
External Dimensions
Width (mm)
1095
Depth (mm)
310
Maximum Total Height (mm)
334
Minimum Total Height (mm)
334
Outlet Diameter (mm)
150, 125
Characteristics
Motor Quantity
1
Motor Model
BT3
Maximum Pressure (Pa)
470
Filter Technology
Aluminium mesh
Control Tecnology
Mechanical push button
Booster
√
Power levels
4
Timer
√
Filter Saturation Indicator
-
Charcoal Filter Change Indicator
-
Dimmer Function
-
Connectivity
No
Remote control
-
Display
-
Lighting
Light Model
SSLED BICOLOR
Lightning Technology
LED
Installation
Minimum distance to an electric cooktop (mm)
550
Minimum distance to a gas cooktop (mm)
650
Recirculation Option
-
Charcoal Filter
√
Back Draught Shutter
No
Inner shield
-
Electric Connection
Rated voltage (V)
220-240
Rated frequency (Hz)
50
Rated power input (W)
283,5
Protection against electric shock
Class II
Accessories
Upper Decorative Duct Extension
02861306
Active Charcoal Filter
02859398
Noiseless Flexible Duct
02893002
