EXTENDER 900
Cod. 02094306
EAN 8422248110310
INFORMACIÓN GENERAL
EAN/UPC
8422248110310
Subfamily
Telescopic
Product fiche according to directives EU65/2014 - EN61591, EN60704-2-13, EN50564
AEC (Energy consumption per year) (kWh/año)
44,5
EEI class (Energy efficiency class)
C
FDE (Fluid dynamic efficiency)
11,9
FDE class (Fluid dynamic efficiency class)
E
LE (Light efficiency) (lux/W)
36
LE class (Light efficiency class)
A
GFE (Grease filtering efficiency)
68
GFE Class (Grease filtering efficiency class)
D
Normal mode airflow MIN (m3/h)
150
Normal mode airflow MAX (m3/h)
390
Normal mode acustic power MIN (dB)
45
Normal mode acustic power MAX (dB)
57
Po (Off-mode power consumption) (W)
0
Ps (Stand-by power consumption) (W)
0
Integration directive EU 66/2014
EEI (Energy efficiency Index)
78,2
QBEP (Maximum airflow point efficiency) (m3/h)
198,2
PBEP (Maximum pressure point efficiency) (Pa)
148
WBEP (Electrical power consumption at maximum efficiency) (W)
68,6
WL (Rated power lighting system) (W)
7
External Dimensions
Width (mm)
700
Depth (mm)
280
Maximum Total Height (mm)
180
Outlet Diameter (mm)
120
Characteristics
Motor Quantity
1
Motor Model
570
Maximum Pressure (Pa)
194
Booster
-
Power levels
2
Timer
-
Connectivity
-
Remote control
-
Display
-
Lighting
Light Model
270D
Lightning Technology
LED
Installation
Minimum distance to an electric cooktop (mm)
550
Minimum distance to a gas cooktop (mm)
650
Recirculation Option
Packaging Label
Charcoal Filter
FalseLabel
Back Draught Shutter
-
Inner shield
√
Electric Connection
Rated voltage (V)
220-240
Rated frequency (Hz)
200
Rated power input (W)
107
Accessories
Upper Decorative Duct Extension
No
White Decorative Duct
No
Black Decorative Duct
No
Island Tube Enhancer
No
Back Draught Shutter
02849003
MAX PRO Metal Filter
No
Active Charcoal Filter
02825263
Noiseless Flexible Duct
No
Recirculating kit
No
