ST-6000 X

Cod. 02060309
EAN 8422248108683
EAN/UPC
8422248108683
Subfamily
Box
AEC (Energy consumption per year) (kWh/año)
36,1
EEI class (Energy efficiency class)
C
FDE (Fluid dynamic efficiency)
9,84
FDE class (Fluid dynamic efficiency class)
E
LE (Light efficiency) (lux/W)
39,6
LE class (Light efficiency class)
A
GFE (Grease filtering efficiency)
72,14
GFE Class (Grease filtering efficiency class)
D
Normal mode airflow MIN (m3/h)
166
Normal mode airflow MAX (m3/h)
292
Normal mode acustic power MIN (dB)
58
Normal mode acustic power MAX (dB)
62,4
Po (Off-mode power consumption) (W)
0
ƒ (Factor Increase in the time)
1,7
EEI (Energy efficiency Index)
75,4
QBEP (Maximum airflow point efficiency) (m3/h)
171
PBEP (Maximum pressure point efficiency) (Pa)
114,29
WBEP (Electrical power consumption at maximum efficiency) (W)
57,27
WL (Rated power lighting system) (W)
2
EMIDDLE (Average illuminance on the cooking surface) (lux)
79
Width (mm)
600
Depth (mm)
500
Maximum Total Height (mm)
998
Minimum Total Height (mm)
548
Outlet Diameter (mm)
150
Motor Quantity
1
Motor Model
TT300
Filter Technology
Aluminium mesh
Control Tecnology
Mechanical push button
Booster
-
Power levels
3
Timer
-
Filter Saturation Indicator
-
Charcoal Filter Change Indicator
-
Dimmer Function
-
Connectivity
No
Remote control
-
Display
-
Light Model
ECOLED STRIP
Lightning Technology
LED
Minimum distance to an electric cooktop (mm)
65
Minimum distance to a gas cooktop (mm)
65
Recirculation Option
Charcoal Filter
-
Back Draught Shutter
Included
Inner shield
-
Rated voltage (V)
220-240
Rated frequency (Hz)
50/60
Rated power input (W)
67
Protection against electric shock
Class I
Plug type
Type C
Upper Decorative Duct Extension
'02863305
Back Draught Shutter
Yes
Active Charcoal Filter
02859495
Noiseless Flexible Duct
02893002
  • :
