OMEGA 900 BK
Cod. 02004410
EAN 8422248190633
INFORMACIÓN GENERAL
EAN/UPC
8422248190633
Subfamily
Chimney
Product fiche according to directives EU65/2014 - EN61591, EN60704-2-13, EN50564
AEC (Energy consumption per year) (kWh/año)
105,4
EEI class (Energy efficiency class)
C
FDE (Fluid dynamic efficiency)
20
FDE class (Fluid dynamic efficiency class)
C
LE (Light efficiency) (lux/W)
21
LE class (Light efficiency class)
B
GFE (Grease filtering efficiency)
90,3
GFE Class (Grease filtering efficiency class)
B
Normal mode airflow MIN (m3/h)
385
Normal mode airflow MAX (m3/h)
645
Normal mode acustic power MIN (dB)
57,8
Normal mode acustic power MAX (dB)
71,8
Po (Off-mode power consumption) (W)
0
Ps (Stand-by power consumption) (W)
0
Integration directive EU 66/2014
ƒ (Factor Increase in the time)
1,3
EEI (Energy efficiency Index)
77,6
QBEP (Maximum airflow point efficiency) (m3/h)
458,1
PBEP (Maximum pressure point efficiency) (Pa)
333,8
WBEP (Electrical power consumption at maximum efficiency) (W)
213
WL (Rated power lighting system) (W)
6
EMIDDLE (Average illuminance on the cooking surface) (lux)
126
External Dimensions
Width (mm)
900
Depth (mm)
500
Maximum Total Height (mm)
1020
Minimum Total Height (mm)
720
Outlet Diameter (mm)
150, 125
Characteristics
Motor Quantity
1
Motor Model
TA
Maximum Pressure (Pa)
430
Filter Technology
Aluminium mesh
Control Tecnology
Mechanical push button
Booster
-
Power levels
3
Timer
-
Filter Saturation Indicator
-
Charcoal Filter Change Indicator
-
Dimmer Function
-
Connectivity
-
Remote control
-
Display
-
Lighting
Light Model
CSLED
Lightning Technology
LED
Installation
Minimum distance to an electric cooktop (mm)
650
Minimum distance to a gas cooktop (mm)
650
Recirculation Option
√
Charcoal Filter
-
Back Draught Shutter
-
Inner shield
-
Electric Connection
Rated voltage (V)
220-240
Rated frequency (Hz)
50
Rated power input (W)
276
Protection against electric shock
Class II
Power cord length (m)
0,7
Plug type
No plug
Accessories
Upper Decorative Duct Extension
02862001
White Decorative Duct
No
Black Decorative Duct
No
Island Tube Enhancer
No
Back Draught Shutter
02832001
MAX PRO Metal Filter
02800917
Active Charcoal Filter
02859391
Noiseless Flexible Duct
02893002
Recirculating kit
02894000
