GT-PLUS 45 WH
Cod. 02030007
EAN 8422248087353
INFORMACIÓN GENERAL
EAN/UPC
8422248087353
Subfamily
Insert
Product fiche according to directives EU65/2014 - EN61591, EN60704-2-13, EN50564
AEC (Energy consumption per year) (kWh/año)
90,3
EEI class (Energy efficiency class)
C
FDE (Fluid dynamic efficiency)
16,3
FDE class (Fluid dynamic efficiency class)
D
LE (Light efficiency) (lux/W)
24,3
LE class (Light efficiency class)
B
GFE (Grease filtering efficiency)
91,2
GFE Class (Grease filtering efficiency class)
B
Normal mode airflow MIN (m3/h)
300
Normal mode airflow MAX (m3/h)
645
Normal mode acustic power MIN (dB)
50
Normal mode acustic power MAX (dB)
65
Po (Off-mode power consumption) (W)
0
Ps (Stand-by power consumption) (W)
0
Integration directive EU 66/2014
ƒ (Factor Increase in the time)
1,4
EEI (Energy efficiency Index)
82,2
QBEP (Maximum airflow point efficiency) (m3/h)
358,1
PBEP (Maximum pressure point efficiency) (Pa)
270
WBEP (Electrical power consumption at maximum efficiency) (W)
164,9
WL (Rated power lighting system) (W)
7
EMIDDLE (Average illuminance on the cooking surface) (lux)
170
External Dimensions
Width (mm)
492
Depth (mm)
277
Maximum Total Height (mm)
280
Minimum Total Height (mm)
280
Outlet Diameter (mm)
150, 125
Characteristics
Motor Quantity
1
Motor Model
BT2
Maximum Pressure (Pa)
400
Filter Technology
Aluminium mesh
Control Tecnology
Mechanical push button
Booster
-
Power levels
3
Timer
-
Filter Saturation Indicator
-
Charcoal Filter Change Indicator
-
Dimmer Function
-
Connectivity
-
Remote control
-
Display
-
Lighting
Light Model
EcoLed
Lightning Technology
LED
Installation
Minimum distance to an electric cooktop (mm)
550
Minimum distance to a gas cooktop (mm)
650
Recirculation Option
√
Charcoal Filter
-
Back Draught Shutter
-
Inner shield
-
Electric Connection
Rated voltage (V)
220-240
Rated frequency (Hz)
50
Rated power input (W)
207
Protection against electric shock
Class II
Power cord length (m)
1,5
Plug type
Type C
Accessories
Upper Decorative Duct Extension
No
White Decorative Duct
No
Black Decorative Duct
No
Island Tube Enhancer
No
Back Draught Shutter
2832004
MAX PRO Metal Filter
No
Active Charcoal Filter
2859398
Noiseless Flexible Duct
2893002
Recirculating kit
No
