CTR-30-M

Cod. 03110001
EAN 8422248081528
EAN/UPC
8422248081528
Subfamily
Electric
Declared Load Profile
S
Water Heating Energy Class
C
Water Heating Energy Efficiency (%)
31,6
Annual electricity consumption (kWh/year)
583
Thermostat temperature settings
75
Capacity (L)
30
Number of persons
1-2
Installation
Vertical
Minimum set temperature
30
Maximum set temperature
75
Type of heating element
Enamel
Heating time 15ºC-65ºC (min)
70,2
Static losses 65ºC (kWh/24h)
0,81
Coating thickness (mm)
5
Type of control
Mechanical
Control position
Bottom
Electrical connection indicator
-
Temperature indicator
Heating indicator
Overheating protection
Safety temperature (ºC)
82
Freezing protection
-
Water protection index
IPX4
Maximum Working Pressure (Mpa)
0,75
Magnesium Anode Dimensions (mm)
160
Rated voltage (V)
220-240
Rated frequency (Hz)
50/60
Rated power input (W)
1500
Protection against electric shock
Class I
Power cord length (m)
1,5
Plug type
Type F
Width (mm)
340
Height (mm)
650
Depth (mm)
340
  • :
