GCX 53 SD
Cod. 02030308
EAN 8422248103572
INFORMACIÓN GENERAL
EAN/UPC
8422248103572
Subfamily
Insert
Product fiche according to directives EU65/2014 - EN61591, EN60704-2-13, EN50564
AEC (Energy consumption per year) (kWh/año)
56,1
EEI class (Energy efficiency class)
A
FDE (Fluid dynamic efficiency)
30,2
FDE class (Fluid dynamic efficiency class)
A
LE (Light efficiency) (lux/W)
26
LE class (Light efficiency class)
B
GFE (Grease filtering efficiency)
91,2
GFE Class (Grease filtering efficiency class)
B
Normal mode airflow MIN (m3/h)
340
Normal mode airflow MAX (m3/h)
600
Boost mode airflow (m3/h)
750
Normal mode acustic power MIN (dB)
50
Normal mode acustic power MAX (dB)
65
Boost mode acustic power (dB)
67
Po (Off-mode power consumption) (W)
0,3
Ps (Stand-by power consumption) (W)
0,3
Integration directive EU 66/2014
ƒ (Factor Increase in the time)
0,9
EEI (Energy efficiency Index)
53
QBEP (Maximum airflow point efficiency) (m3/h)
429,4
PBEP (Maximum pressure point efficiency) (Pa)
405
WBEP (Electrical power consumption at maximum efficiency) (W)
159,8
WL (Rated power lighting system) (W)
5
EMIDDLE (Average illuminance on the cooking surface) (lux)
130
External Dimensions
Width (mm)
830
Depth (mm)
280
Maximum Total Height (mm)
316
Minimum Total Height (mm)
316
Outlet Diameter (mm)
150
Characteristics
Motor Quantity
1
Motor Model
BT3
Maximum Pressure (Pa)
450
Filter Technology
Aluminium mesh
Control Tecnology
Electronic Touch Control
Booster
√
Power levels
4
Timer
√
Filter Saturation Indicator
√
Charcoal Filter Change Indicator
-
Dimmer Function
√
Connectivity
-
Remote control
-
Display
Display_grafico
Lighting
Light Model
SSLED BICOLOR
Lightning Technology
LED
Installation
Minimum distance to an electric cooktop (mm)
550
Minimum distance to a gas cooktop (mm)
650
Recirculation Option
√
Charcoal Filter
-
Back Draught Shutter
Included
Electric Connection
Rated voltage (V)
220-240
Rated frequency (Hz)
50
Rated power input (W)
285
Protection against electric shock
Class II
Power cord length (m)
1,5
Accessories
Upper Decorative Duct Extension
N_A
White Decorative Duct
N_A
Black Decorative Duct
N_A
Island Tube Enhancer
N_A
MAX PRO Metal Filter
N_A
Active Charcoal Filter
2859398
Noiseless Flexible Duct
2893002
Recirculating kit
No
