GL 45 X
Cod. 02030305
EAN 8422248077842
INFORMACIÓN GENERAL
EAN/UPC
8422248077842
Subfamily
Insert
Product fiche according to directives EU65/2014 - EN61591, EN60704-2-13, EN50564
AEC (Energy consumption per year) (kWh/año)
58,3
EEI class (Energy efficiency class)
A
FDE (Fluid dynamic efficiency)
30,2
FDE class (Fluid dynamic efficiency class)
A
LE class (Light efficiency class)
B
GFE (Grease filtering efficiency)
91,2
GFE Class (Grease filtering efficiency class)
B
Normal mode airflow MIN (m3/h)
0
Normal mode airflow MAX (m3/h)
600
Normal mode acustic power MIN (dB)
50
Normal mode acustic power MAX (dB)
65
Boost mode acustic power (dB)
67
Integration directive EU 66/2014
ƒ (Factor Increase in the time)
0,9
EEI (Energy efficiency Index)
54,40000
PBEP (Maximum pressure point efficiency) (Pa)
405
WBEP (Electrical power consumption at maximum efficiency) (W)
159,8
WL (Rated power lighting system) (W)
7
External Dimensions
Width (mm)
492
Depth (mm)
Warranty Document
Minimum Total Height (mm)
280
Outlet Diameter (mm)
150, 125
Characteristics
Motor Quantity
1
Motor Model
BT3
Maximum Pressure (Pa)
450
Control Tecnology
Electronic Touch Control
Booster
457
Power levels
4
Timer
√
Filter Saturation Indicator
√
Charcoal Filter Change Indicator
-
Dimmer Function
320
Remote control
-
Display
Palletization Procedure
Lighting
Lightning Technology
Icons
Installation
Minimum distance to an electric cooktop (mm)
550
Minimum distance to a gas cooktop (mm)
650
Charcoal Filter
$se
Back Draught Shutter
Insert
Inner shield
-
Electric Connection
Rated voltage (V)
220-240
Rated frequency (Hz)
50
Rated power input (W)
287
Plug type
Type C
Accessories
Upper Decorative Duct Extension
No
White Decorative Duct
No
Black Decorative Duct
No
Island Tube Enhancer
No
Back Draught Shutter
2832004
MAX PRO Metal Filter
No
Active Charcoal Filter
2859398
Noiseless Flexible Duct
2893002
Recirculating kit
No
